Used Hyundai HiT 8G Gang Tool CNC Turning Center Lathe Seimens LNS Barfeed 1998

Used Hyundai HiT 8G Gang Tool CNC Turning Center Lathe Seimens LNS Barfeed 1998

Condition: Used
“Machine is clean and in good running condition.”

Specifications:

Max Swing……………………………………………………………………… 11.8″
Max Cutting Diameter ……………………………………………………….. 6.3″
X-Axis Travel …………………………………………………………………. 19.3″
Z-Axis Travel …………………………………………………………………. 12.0″
Spindle Bore …………………………………………………………………… 1.97″
Max Bar Capacity ……………………………………………………………. 1.57″
Spindle Nose …………………………………………………………………… A2-5
Spindle Speed …………………………………………………………. 6000 RPM
Spindle Drive Motor ………………………………………………………. 10 HP
Spindle Torque ………………………………………………………… 63.5 ft/lbs
Rapid Traverse-X/Z ………………………………………….. 1180/1180 IPM
Approx Dimensions ……………………………………….. 53″ x 68.5″ x 70″
Approx Weight ………………………………………………………….. 5950 lbs

Equipped With:

Siemens Controller
LNS 12 Foot Super Hydrobar
ATS 16C Collet Chuck
Tool Presetter
All Available Tool Holders
All Available Manuals
